Oakridge Meadows – Phase 2

DETACHED

EXTERIOR & CUSTOM CONSTRUCTION FEATURES:
1 Every Royal Pine Home complements the neighbourhood with master-planned elevations, quality old-style craftsmanship and architecturally
co-ordinated colour exteriors based on the community’s Urban design guidelines to achieve a variety within the streetscape. Purchaser to have the
choice of a brick package for a single detached unit (Subject to Architectural Controls).
2 Clay brick construction with accent stone, stucco, decorative “Hardie” board, decorative metal and aluminum frieze board, soldier coursing,
precast concrete window sills, keystones, exterior railings as required by grade, as per plan and model selected.
3 Superior 2”x 6” wood exterior wall construction plus 1/2” wall sheathing (R-1.5 factor) as per architectural drawings and model selected.
4 Quality 5/8” spruce tongue & grove plywood subflooring throughout sanded and fastened with screws for additional stability.
5 Engineered floor joist technology throughout.
6 Approximate 9’ high poured concrete basement walls as per plan with heavy duty drainage layer membrane on all exterior foundation walls as per Ontario Building Code Standards
7 Custom precast individual house numbers.
8 Poured concrete front porch and steps as required by grade, as per plan.
9 Elegant black hardware package including grip set(s) with dead bolt lock and coach lamps on front elevation. Standard light fixtures to rear and side doors, as per model where applicable, as per Vendor’s samples.
10 CONVENIENT DIRECT ACCESS FROM GARAGE LEADING TO MAIN LEVEL, grade permitting, as per model, as per plan.
11 Prominent steel clad insulated entry door(s) with magnetic weather stripping to include GLASS INSERTS WITH 12”TRANSOM WINDOW ABOVE as per elevation. All front door to be complemented with Granite sills. Where applicable a 36” wide single door and side lights as per model and elevation selected, as per plan, as per Vendor’s samples
12 Limited life (manufacturer’s warranty), self sealing asphalt shingles, as per Vendor’s samples, as per model selected.
13 Durable pre-finished maintenance free aluminum soffits, fascia, eavestrough and down spouts, as per model selected, as per Vendor’s samples.
14 “Energy Star” low maintenance thermopane vinyl casement windows throughout. Screens throughout, except on fixed windows, as per Vendor’s samples.
15 Extra wide up to 9 ft. x 8 ft. high patio sliding doors for 45’ & 50’ models & 6 ft wide x 8 ft high patio sliding doors for 38’ models with low E argon gas as per plan and model
16 Standard vinyl basement windows 30”x 24” with screens, (except cold cellar) as per plan and model selected, as per Vendor’s samples.
17 Roll-up sectional garage doors with decorative glass inserts, as per elevation & model selected, as per Vendor’s samples.
18 ASPHALT paved driveway to include base and finish coats, as per Vendor’s specifications.
19 Walkways, precast slabs and steps at front and rear patio area, where applicable as per model, as per Vendor’s specifications and as per approved municipal drawings.
20 Front and rear of lot to be graded and sodded. Side yard between homes will be finished as per municipal requirements or at the Vendor’s discretion.
21 Exterior hose bibs installed as follows: one located at rear and one located in garage area.
22 Decks at rear of model at ground level where applicable, as required by grade, as per Vendor’s specifications.
23 Romeo & Juliet balcony at rear for walk-out condition, where applicable, as required by grade, as per Vendor’s specifications
24 Cold cellar, as per plan.
25 Rough-in 3 piece bathroom in basement, as per plan. (Not including water supply) Location predetermined by the Vendor and may vary from brochure

KITCHEN:
26 Bright appealing spacious extended height kitchen cabinets with large eat-in areas as per plan.
27 CUSTOM QUALITY cabinets and QUARTZ COUNTERTOPS with extended breakfast counters and islands, as per plan, from Vendor’s samples.
28 Stainless steel exhaust hood fan over stove area with 6” exhaust vented outside.
29 Heavy duty wiring and receptacle for stove.
30 Electrical outlets for fridge and at counter level for small appliances
31 Rough-in PLUMBING & ELECTRICAL for future dishwasher.
32 DOUBLE STAINLESS STEEL UNDERMOUNT SINK WITH SINGLE LEVER FAUCET with shut-off valve, as per Vendor’s samples.
33 Kitchen backsplash (above counter only) as per Vendor’s samples, as per plan.

BATHROOMS:
34 Purchaser’s choice of vanity cabinets and QUARTZ countertops in all bathrooms as per Vendor’s samples.
35 Elegant master ensuite bathroom features a free-standing soaker tub and shower stall with frameless 10mm tempered glass shower door and
panel and shower light according to plan as per Vendor’s samples.
36 Purchaser’s extensive choice of quality imported 8”x 10” or 13” x 13” ceramic floor and wall tiles to all tub & shower enclosures up to but not
including the ceiling, as applicable.
37 All shower areas completed with “Dens-Shield” water resistant board, as per Vendor’s samples, as per plan.
38 Temperature control valve in all shower areas, as per Vendor’s samples.
39 Exhaust fan in all bathrooms (as required) according to the Ontario Building Code.
40 Privacy locks on all bathroom doors, as per Vendor’s samples.
41 Plate mirrors above vanities in all bathrooms.
42 Powder room includes “FLOATING” VANITY with QUARTZ countertop and undermount sink, according to plan, as per Vendor’s samples.
43 Single lever chrome faucets with pop-up drains and undermount sinks for all bathroom vanities with shut-off valves, as per Vendor’s samples.
44 White plumbing fixtures in all bathrooms from Vendor’s standard samples.

LAUNDRY:
45 Base cabinet with white arborite countertop and single laundry tub with faucet & drain, as per plan
46 Dryer vent and heavy-duty electrical outlet & plumbing for automatic washer. Upper level laundry areas, as per model, to have floor drains, as per plan

FLOORING:
47 Purchaser’s choice of IMPORTED CERAMIC TILES 18” x 18” or 20” x 20” in foyer, main/ground level hallways (according to plan), kitchen, powder room, and laundry room, as per plan, as per Vendor’s samples.
48 HIGH QUALITY 40 OZ BROADLOOM (1 colour throughout) in bedroom areas, as per plan, as per Vendor’s samples
49 STAINED 3 ¼” X 3/4” OAK HARDWOOD FLOORS in all areas not covered with ceramic tiles on main/ground levels and upper hallway, including stair landings, as per plan

ELECTRICAL:
50 200 AMP electrical service plus one electrical outlet next to panel.
51 All wiring in accordance with the Ontario Hydro Standards.
52 10 LED pot lights on main floor. Location to be chosen by the Purchaser at the Design Studio and approved by construction.
53 Capped Rough-in EV conduit from garage to basement for future car charger
54 Weatherproof GFI exterior electrical outlet as follows: one located at rear and one located at front porch, as per plan
55 Rough-in provisions for future central vacuum terminating in the basement.
56 Rough-in provisions for alarm system. (Key pad in master bedroom & motion detector in upper hall. Wire for keypad at main entrance, wire for all operating doors and windows on main floor, space wire brought to attic for future use.)
57 Master bedroom and family room/great room are pre-wired for TV with CAT6 cable.
58 Telephone rough-in in master bedroom and kitchen.
59 USB plugs in kitchen and master bedroom
60 Conduit (3/4”) to basement from family room
61 Standard light fixtures with LED bulbs throughout except living room.
62 Standard light fixtures in all bedrooms.
63 One electrical outlet on the garage wall and one on the garage ceiling for each garage door for future garage door opener and one in unfinished area of basement near electrical panel.
64 One ceiling light in garage area and in unfinished areas (where required) of basement as per Ontario Building Code
65 Smoke detectors with strobe lighting & carbon monoxide sensors per floor as per Ontario Building Code.
66 Electrical door chime.
67 White Decora switches and receptacles throughout complete with screwless wall plates as per Vendor’s samples.

HEATING:
68 High efficiency (96% AFUE) forced air gas heating system, as per plan, as per Vendor’s specifications. ECM motor with two-zone prioritization as per plan, as per Vendor’s samples. Furnace & hot water tank location may vary from that shown on brochure or plan.
69 Heat Recovery Ventilation (HRV) system, as per Vendor’s samples
70 Power vented high efficiency water heater on a rental basis as per Vendor’s samples (Purchaser agrees to execute a lease agreement with the Vendor’s supplier on or before closing.)
71 Programmable thermostat(s), as per plan, as per Vendor’s samples.
72 Standard line set to accommodate provisions for central air conditioning.
73 R-22 wall insulation.
74 Blown insulation (R-60 factor) in attic
75 R-20 insulated basement walls that terminate 15” above cement slab.
76 R-31 spray foam insulation in exposed floor areas (above the garage with liveable area above, as per plan)
77 Fully drywalled taped and primed garage walls and ceiling, as per Ontario Building Code.
78 Professional duct cleaning provided prior to closing.
79 Drain water heat recovery pipe, as per Vendor’s samples and specifications

DISTINCTIVE FEATURES INCLUDE:
80 Extended 10’ ceiling heights on MAIN level on 45’ and 50’ models. 38’ models to include 9’ ceiling heights on main level including extended height archways, (excluding areas due to mechanical or structural requirements) as per plan.
81 Extended 9’ ceilings heights on 2nd level, (excluding areas due to mechanical or structural requirements) as per plan
82 Gas fi replace with stonecast mantle, as per Vendor’s samples and as per plan.
83 Approximate 8’ high Interior doors on MAIN level for 45’ & 50’ models only.
84 Smooth Carrara (2-panel hollow core) style interior doors throughout, as per Vendor’s samples.
85 Interior doors to include satin nickel lever handles and 3” upgraded hinges – as per Vendor’s samples.
86 For 45’ & 50’ Models, Choice of traditional or contemporary 7 1/4” BASEBOARDS and 3” CASING on MAIN floor and 5 ¼” BASEBOARDS and 3” CASING the 2nd Floor, all in paint grade, as per Vendor’s samples
87 For 38’ Models, Choice of traditional or contemporary 5 ¼” BASEBOARDS and 3” CASING for the MAIN and 2nd Floor, all in paint grade, as per Vendor’s samples.
88 Doors & trim work to be painted white as per Vendor’s samples.
89 Painted walls according to Purchaser’s choice of one colour as per Vendor’s samples.
90 All closets and linen closets to include wire shelving, as per Vendor’s samples
91 Smooth ceilings on main level and including the upper hallway. Sprayed stipple ceiling with smooth border surround in all other rooms/areas.
92 STAINED OAK STAIRCASE, HANDRAIL, STRINGERS to include METAL PICKETS from MAIN to 2nd Floor (excluding landings), as per plan, as
per Vendor’s samples. Any other steps (required as per grade levels) at the main level and not forming part of the main staircase will also be completed WITH STAINED OAK steps.
93 Durable, condensation-free, noise free plastic pipe throughout
94 Painted pine stairs leading to basement.

TOWNHOME

EXTERIOR & CUSTOM CONSTRUCTION FEATURES
Every Royal Pine Home complements the neighbourhood with masterplanned elevations, quality old-style craftsmanship and architecturally co-ordinated colour exteriors based on the community’s Urban design guidelines to achieve a variety within the streetscape. Townhouse brick packages will be preselected by the Vendor and architecturally controlled.
Clay brick construction with accent stone, stucco, decorative “Hardie” board, decorative metal and aluminum frieze board, soldier coursing, precast concrete window sills, keystones, exterior railings as required by grade, as per plan and model selected.
Superior 2″ x 6″ wood exterior wall construction plus 1/2″ wall sheathing (R-1.5 factor) as per architectural drawings and model selected.
Offset 2″ x 4″ stud fire-rated party walls and sound attenuation insulation as per OBC standards.
Quality 5/8″ spruce tongue & groove plywood subflooring throughout sanded and fastened with screws for additional stability.
Engineered floor joist technology throughout.
Approximate 9′ high poured concrete basement walls as per plan with heavy duty drainage layer membrane on all exterior foundation walls as per Ontario Building Code Standards.
Custom precast individual house numbers.
Poured concrete front porch as required by grade, as per plan.
Elegant black hardware package including grip set(s) with dead bolt lock and coach lamps on front elevation. Standard light fixtures to rear and side doors, as per model where applicable, as per Vendor’s samples.
CONVENIENT DIRECT ACCESS FROM GARAGE LEADING TO MAIN LEVEL, grade permitting, as per model, as per plan.
Prominent steel clad insulated entry door(s) with magnetic weather stripping to include GLASS INSERTS WITH 12″TRANSOM WINDOW ABOVE as per elevation. All front door to be complemented with granite sills. Where applicable a 36″ wide single door and side lights as per model and elevation selected, as per plan, as per Vendor’s samples.
Limited life (manufacturer’s warranty), self-sealing asphalt shingles as per Vendor’s samples, as per model selected.
Durable pre-finished maintenance free aluminum soffits, fascia, eavestrough and down spouts, as per model selected, as per Vendor’s samples.
“Energy Star” low maintenance thermopane vinyl casement windows throughout. Screens throughout, except on fixed windows, as per Vendor’s samples.
Extra wide 6 ft. x 8 ft. patio sliding doors with low E argon gas as per plan, as per model selected.
Standard vinyl basement windows 30″x 24″ with screens,(excluding cold cellar) as per plan and model selected, as per Vendor’s samples.
Roll-up sectional garage doors with decorative glass inserts, as per elevation & model selected, as per Vendor’s samples.
Asphalt paved driveway to include base and finish coats as per Vendor’s specifications.
Walkways, precast slabs and steps at front and rear patio area, where applicable as per model, as per Vendor’s specifications and as per approved municipal drawings.
Front and rear of lot to be graded and sodded. Side yard between homes will be finished as per municipal requirements or at the Vendor’s discretion.
Exterior hose bibs installed as follows: one located at rear and one located in garage area.
Decks at rear of model at ground level where applicable, as required by grade, as per Vendor’s specifications.
Romeo & Juliet balcony at rear, where applicable, as required by grade, as per Vendor’s specifications.
Cold cellar, as per plan.
Rough-in 3 piece bathroom in basement, as per plan (not including water supply). Location predetermined by the Vendor and may vary from brochure.

KITCHEN
Bright appealing spacious extended height kitchen cabinets with large eat-in areas as per plan.
CUSTOM QUALITY cabinets and QUARTZ countertops with extended breakfast counters and islands, as per plan, from Vendor’s samples.
Stainless steel exhaust hood fan over stove area with 6″ exhaust vented outside, as per Vendor’s samples.
Heavy duty wiring and receptacle for stove.
Electrical outlets for fridge and at counter level for small appliances.
Rough-in PLUMBING & ELECTRICAL for future dishwasher.
DOUBLE STAINLESS STEEL UNDERMOUNT SINK WITH SINGLE LEVER FAUCET with shut-off valve, as per Vendor’s samples.
KITCHEN BACKSPLASH (above counter only) as per Vendor’s samples, as per plan.

BATHROOMS
Purchaser’s choice of vanity cabinets and QUARTZ countertops in all bathrooms as per Vendor’s samples.
Elegant master ensuite bathroom features a free standing soaker tub and shower stall with chrome framed glass shower door and panel and shower light according to plan as per Vendor’s samples.
Purchaser’s extensive choice of quality imported 8″x 10″ or 13″ x 13″ ceramic floor and wall tiles to all tub & shower enclosures up to but not including the ceiling, as applicable.
All shower areas completed with “Dens-Shield” water resistant board, as per Vendor’s samples, as per plan.
Temperature control valve in all shower areas, as per Vendor’s samples.
Exhaust fan in all bathrooms (as required) according to the Ontario Building Code.
Privacy locks on all bathroom doors, as per Vendor’s samples.
Plate mirrors above vanities in all bathrooms.
Plate mirrors above vanities in all bathrooms.
Powder room includes “FLOATING” VANITY with QUARTZ countertop and undermount sink, according to plan, as per Vendor’s samples.
Single lever chrome faucets with pop-up drains and undermount sinks for all bathroom vanities with shut-off valves, as per Vendor’s samples.
White plumbing fixtures in all bathrooms from Vendor’s standard samples.

LAUNDRY
Single laundry tub with faucet and drain as per Vendor’s samples, according to plan.
Dryer vent and heavy-duty electrical outlet and plumbing for automatic washer. Upper level laundry areas, as per model, to have floor drains, as per plan.

FLOORING
Purchaser’s choice of IMPORTED CERAMIC TILES 13″ x 13″ in foyer, main/ground level hallways (according to plan), kitchen, powder room, and laundry room, as per plan, as per Vendor’s samples.
HIGH QUALITY 40 OZ BROADLOOM (1 colour throughout) on upper level on areas without ceramic tiles, as per plan, as per Vendor’s samples.
Choice of Colour for 7 1/2″ LAMINATE ENGINEERED FLOORING in all areas not covered with ceramic tiles on main/ground levels, including stair landings, as per plan, as per Vendor’s samples.

ELECTRICAL
100 AMP electrical service plus one electrical outlet next to panel.
All wiring in accordance with the Ontario Hydro Standards.
10 LED pot lights on main floor. Location to be determined by Purchaser at Design Studio.
Capped Rough-in EV conduit from garage to basement for future car charger.
Weatherproof GFI exterior electrical outlet as follows: one located at rear and one located at front porch, as per plan.
Rough-in provisions for future central vacuum terminating in the basement.
Rough-in provisions for alarm system. (Key pad in master bedroom & motion detector in upper hall. Wire for keypad at main entrance, wire for all operating doors and windows on main floor, space wire brought to attic for future use).
Master bedroom and family room/great room are pre-wired for TV with CAT6 cable.
Telephone rough-in in master bedroom and kitchen.
USB plugs in kitchen and master bedroom.
Conduit (3/4″) to basement from family room.
Standard light fixtures with LED bulbs throughout except living room.
Standard light fixtures in all bedrooms.
One electrical outlet on the garage wall and one on the garage ceiling for each garage door for future garage door opener and one in unfinished area of basement under electrical panel.
One ceiling light in garage area and in unfinished areas (where required) of basement as per Ontario Building Code.
Smoke detectors with strobe lighting & carbon monoxide sensors per floor as per Ontario Building Code.
Electrical door chime.
White Decora switches and receptacles throughout as per Vendor’s samples./li>

HEATING
High efficiency (96% AFUE) forced air gas heating system, with 2 stage ECM motor as per plan, as per Vendor’s samples. Furnace & hot water tank location may vary from that shown on brochure or plan.
Heat Recovery Ventilation (HRV) system, as per Vendor’s samples.
Power vented high efficiency water heater on a rental basis as per Vendor’s samples (Purchaser agrees to execute a lease agreement with the Vendor’s supplier on or before closing).
Programmable thermostat(s), as per plan, as per Vendor’s samples.
Standard line set to accommodate provisions for central air conditioning.
R-22 wall insulation.
Blown insulation (R-60 factor) in attic.
R-20 insulated basement walls that terminate 15″ above cement slab.
R-31 spray foam insulation in exposed floor areas (above the garage with liveable area above, as per plan).
Fully drywalled taped and primed garage walls and ceiling, as per Ontario Building Code.
Professional duct cleaning provided prior to closing.
Drain water heat recovery pipe, as per Vendor’s samples and specifications.

DISTINCTIVE FEATURES INCLUDE
Extended 9′ ceiling heights on main level including extended height archways,(excluding areas due to mechanical or structural requirements) as per plan.
Extended 9′ ceiling heights on 2nd level (excluding areas due to mechanical or structural requirements) as per plan.
Painted walls according to Purchaser’s choice of one colour as per Vendor’s samples.
Smooth Carrara (2-panel hollow core) style interior doors, as per Vendor’s samples.
Doors & trim work to be painted WHITE as per Vendor’s samples.
Interior doors to include satin nickel lever handles and standard 3″ hinges as per Vendor’s samples.
4 1/4″ BASEBOARDS and 2 3/4″ CASING in paint grade, as per Vendor’s samples.
Smooth ceilings ON MAIN LEVEL ONLY. Sprayed stipple ceiling with smooth border surround in all other rooms/areas.
STAINED OAK STAIRCASE, HANDRAIL, STRINGERS to include METAL PICKETS from MAIN to 2nd floor (excluding landings), as per plan, as per Vendor’s samples. Any other steps (required as per grade levels) at the main level and not forming part of the main staircase will also be completed WITH STAINED OAK steps.
Pine painted stairs leading to basement.
Durable, condensation-free, noise free plastic plumbing pipe throughout.
All closets and linen closets to include wire shelving, as per Vendor’s samples.
